It is mainly used on delivery room, baby wards, NICU that the baby’s maximum weight up to 10KG.

The different concentrations of medical oxygen will be configured by adjusting the proportion of oxygen and air.

Inside an alarm system of differential pressure. When alarming, the safety valve starts automatically, and produces the mixture gas continuously to ensure the safety of patients,

Adjust the oxygen concentration from 21%~100%.

The range of flow adjustment is 5LPM~15LPM.

The MAX-P and PIP are safe, controlled and accurate.

The PEEP is constant and accurate.

Simple operation and flexible application.

The output pressure would not be influenced by the operator’s experience, training, attention and fatigue.

Instead of temporary breathing support.

Technical Parameter:

Flow control: 5LPM~15LPM

Oxygen concentration: 21%~100%

Air supply failure: While air source interrupted or the pressure difference more than 0.1MPa,it shall alarmed by sound

Sound alarm: At least continue 60s,and the level of sound shall more than 60dB(A)

Pressure gauge: -2~10KPa(-20~100cmH2O)

MAX-P: @ 0~15LPM ≤6kPa(60cmH2O)

PIP: @5~15LPM 0.2~5.7kPa(2~57cmH2O)

PEEP: @5~15LPM 0.03~2.3kPa(0.3~23cmH2O)

Working noise: ≤55dB(A)

Suggestions for weight range: max.10KG

Work and store limit: -20℃~50℃, relative humidity up to 90%

Work hours(400L gas cylinder): @8LPM /50mins

Quality certification: ISO 13485
