Usage

Orthopedics: restore bone translocation, reset, fixing

Surgery: taking foreign bodies out of the body, cardiac catheterization, implantable pacemakers, some of angiography and local photography etc.

Features

1. New integrated design of TV system and mainframe, it does not need to connect electric cable, so the operation is more convenient.

2. High-quality combined HF-HV X-ray generator with our high voltage cable, it reduces loss and the quality of x-ray and image are good.

3. Electric rotating lead piece iris beam limiting device, it can satisfy multi-angle and multi-direction anatomical display.

4. The machine adopts imported image intensifier, matching with high-definition and high-resolution CCD and progressive scan display system, which matches with image system better.

5. With the perspective KV, MA automatic tracking feature, the image brightness and definition are automatically set at optimal function.

6. Graphical colorfully LCD touchable screen console interface, the operation is convenient and intelligent.

7. Unique hand-held remote controller, the doctor can operate it a far distance, so it’s more convenient.

Standard Configurations

1. New integrated C-arm mainframe 1set

2. Combined high-frequency high-voltage X-ray generator and high-frequency power supply (5.0kW, 40 kHz, 120kV) 1 set

3. Imported 9 inch image intensifier 1 set

4. Imported ultra-low illumination CCD radiography 1 set

5. High-definition progressive output CCU control system 1 set

6. Imported dense grain grids 1 set

7. Electrical adjustable beam limiting device 1 set

8.14-inch high-definition medical dedicated monitor 1 set

9. Unique hand-held controller 1set
